Panasonic Lumix S1R User Manual

7. Drive/Shutter
164
Selecting the Focus Position for the Picture to Save
1
Select a Post-Focus image on
the playback screen. (l 259)
≥Select an image with the [ ]
icon and then press 3.
≥You can also perform the same
operation by touching the [ ]
icon.
2
Touch the point to be brought
into focus.
0 When the point is in focus, a green frame
appears.
0 If there is no picture with the selected
point in focus, a red frame appears.
A picture cannot be saved.
0 The edge of the screen cannot be selected.
3
Save the picture.
≥Touch [ ].
0
The picture is saved in JPEG format.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
