2. Getting Started
49
You can attach the Leica Camera AG L-Mount standard lens to this
camera.
For information about the lens that can be used, refer to page 21.
1
Turn off the camera.
2
Turn the lens rear cap and the body cap in the direction
of the arrow to remove them.
≥When removing the body cap, rotate it while pressing the lens
release button A.
Attaching a Lens
0 Change the lens in a location where there is not a lot of dirt and dust. If dirt or
dust gets on the lens, refer to page 472.
0 Change the lens while the lens cap is attached.



Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix S1R and is the answer not in the manual?

Panasonic Lumix S1R Specifications

General IconGeneral
Sensor Resolution47.3MP
Sensor TypeFull-frame CMOS
ISO Sensitivity100-25600 (expandable to 50-51200)
Image ProcessorVenus Engine
Image Stabilization5-axis in-body image stabilization
Camera TypeMirrorless
Sensor Size36 x 24 mm
Lens MountL-Mount
Shutter Speed1/8000 to 60 sec, Bulb
ConnectivityWi-Fi, Bluetooth
BatteryDMW-BLJ31 Lithium-Ion
Dimensions148.9 x 110.0 x 96.7 mm
Autofocus SystemContrast Detection AF System with DFD Technology
Viewfinder5.76 million dots OLED EVF
LCD Screen3.2-inch, 2.1 million dots, touch screen
Video Recording4K up to 60p
Continuous Shooting9 fps (AFS/MF), 6 fps (AFC)
Weather SealingYes
Memory Card Slots2x SD Card Slots (1x UHS-II Compatible)
