2. Getting Started
50
3
Align the lens fitting marks B on the lens and camera
and then rotate the lens in the direction of the arrow.
≥Attach the lens by rotating it until it clicks.
îš™
Removing a Lens
1
Turn off the camera.
2
While pressing the lens release button
A, rotate the lens in the direction of the
arrow until it stops and then remove it.
0 Insert the lens straight in.
Inserting this at an angle to attach it may damage the camera lens mount.
0 After removing the lens, be sure to attach the body cap and the lens rear cap.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix S1R and is the answer not in the manual?

Panasonic Lumix S1R Specifications

General IconGeneral
Sensor Resolution47.3MP
Sensor TypeFull-frame CMOS
ISO Sensitivity100-25600 (expandable to 50-51200)
Image ProcessorVenus Engine
Image Stabilization5-axis in-body image stabilization
Camera TypeMirrorless
Sensor Size36 x 24 mm
Lens MountL-Mount
Shutter Speed1/8000 to 60 sec, Bulb
ConnectivityWi-Fi, Bluetooth
BatteryDMW-BLJ31 Lithium-Ion
Dimensions148.9 x 110.0 x 96.7 mm
Autofocus SystemContrast Detection AF System with DFD Technology
Viewfinder5.76 million dots OLED EVF
LCD Screen3.2-inch, 2.1 million dots, touch screen
Video Recording4K up to 60p
Continuous Shooting9 fps (AFS/MF), 6 fps (AFC)
Weather SealingYes
Memory Card Slots2x SD Card Slots (1x UHS-II Compatible)
