Panasonic Lumix S1R User Manual

3. Basic Operations
67
Switching Between the Monitor and Viewfinder
With the default settings, automatic viewfinder/monitor switching is set.
When you look through the viewfinder, the eye sensor works and the
camera switches from monitor display to viewfinder display.
You can switch to viewfinder display or monitor display with [LVF].
Press [LVF] A.
B Eye sensor
Automatic viewfinder/
monitor switching
Viewfinder display Monitor display
0 The eye sensor may not work correctly due to the shape of eyeglasses, the
way the camera is held, or bright light shining around the eyepiece.
0 The camera does not switch between the viewfinder and monitor
automatically during video playback.
0 When the monitor is open, the eye sensor does not work.
0 To focus when looking through the viewfinder:
[] ¨ [ ] ¨ [Eye Sensor AF] (l 332)
0 The sensitivity of the eye sensor can be changed:
[] ¨ [ ] ¨ [Eye Sensor] (l 353)

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
