14. Menu Guide
332
[Focus/Shutter] ¨ ¨
[AF-Point Scope
Setting]
[Keep Enlarged
Display]
[ON]/`[OFF]
[PIP Display] [FULL]/`[PIP]
Changes the enlarged screen settings of AF-Point Scope
(l 94).
[Keep Enlarged Display]: Setting this to [ON] maintains the
enlarged screen after pressing the Fn button until it is
pressed again.
[PIP Display]: Sets the display method (windowed mode/full
screen mode) of the enlarged screen.
[Shutter AF]
`[ON]/[OFF]
This adjusts focus automatically when you press the shutter
button halfway.
[Half-Press Shutter]
[ON]/`[OFF]
You can release the shutter quickly by pressing the shutter
button halfway.
[Quick AF]
[ON]/`[OFF]
When the amount of camera blur becomes small, the
camera will automatically adjust the focus and focus
adjustment will then be quicker when the shutter is pressed.
0 The battery will drain faster than usual.
0 This function is not available in the following cases:
– In preview mode
– In low light situations
[Eye Sensor AF]
[ON]/`[OFF]
When looking through the viewfinder, if the eye sensor
operates, then AF will function.
0 [Eye Sensor AF] may not work in low light situations.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
