Panasonic Lumix S1R User Manual

14. Menu Guide
352
[Monitor / Display] ¨ ¨
[Monitor Settings]/
[Viewfinder]
[Brightness]/[Contrast]/[Saturation]/[Red Tint]/[Blue Tint]
This adjusts the brightness, colouring, and red or blue tints
of the monitor/viewfinder.
1 Press 34 to select the setting item, and press 21 to
adjust.
2 Press or to confirm the setting.
0 It will adjust the monitor when the monitor is in use, and
the viewfinder when the viewfinder is in use.
[Monitor Backlight]/
[LVF Luminance]
`[AUTO]/[j3] to [r3]
Adjusts monitor/viewfinder luminance.
[AUTO]: The brightness is adjusted automatically
depending on how bright it is around the camera.
0 Adjusts the monitor luminance when displaying the
monitor, and the viewfinder luminance when displaying the
viewfinder.
0 When either [AUTO] is set, or the adjusted value is set to
positive side, the usage period will shorten.
0 [AUTO] is not available on the playback screen.
0 When [Night Mode] is being used, [Monitor Backlight]/[LVF
Luminance] are not available.
[Remaining Battery
Level]
`[ ]/[%]
Switches the battery remaining level display between a bar
and a percentage (%) display.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
