Panasonic Lumix S1R

1. Introduction
28
Supplied Lens
S-R24105
7 8 91 2 3 4 5 6
1
Lens surface
2
Focus ring (l 118)
3 Zoom ring (l 121)
4
O.I.S. switch (l 173)
5
[AF/MF] switch (l 92, 117)
0 You can switch between AF and
MF.
If [MF] is set on either the lens or
camera, operation will be with
MF.
6
Zoom lock switch
0 When you set the focal length to
24 mm and set the switch to
[LOCK], the zoom ring is locked.
7
Contact points
8
Lens mount rubber (l 474)
9 Lens fitting mark (l 50)
