1. Introduction
27
3
4
6
5
16 15 14 1317 118
2
1
12
11
10
9
7
8
1 Shoulder strap eyelet (l 31)
2
Self-timer lamp (l 153)/
AF assist lamp (l 309)
3
Fn button (Fn1) (l 278)
4
Grip
5
Preview button (l 188)/
Fn button (Fn2) (l 278)
6
Lens release button (l 50)
7
Flash synchro socket (flash
synchro socket cap) (l 217)
0 Keep the flash synchro socket
cap out of reach of children to
prevent swallowing.
8
[REMOTE] socket (l 446)
9 [MIC] socket (l 253)
10
Headphone socket (l 257)
0 Excessive sound pressure from
earphones and headphones can
cause hearing loss.
11
USB port (l 433, 441)
12
[HDMI] socket (l 426)
13
Fn lever (l 286)
14
Mount
15
Contact points
16
Sensor
17
Lens lock pin
18 Lens fitting mark (l 50)
