Panasonic Lumix S1R User Manual

10. Flash
217

Connecting a Synchro Cable to the Flash Synchro Socket
You can use a commercially available external flash by connecting a
commercially available synchro cable to the flash synchro socket.
The socket has a lock screw to prevent the cable from falling off.
Before connecting the synchro cable to the flash synchro socket, remove
the flash synchro socket cap.
1
Rotate the flash synchro socket cap in
the direction of the arrow to remove.
0
Be careful not to lose the flash synchro
socket cap.
2
Connect the synchro cable to the flash
synchro socket.
0
For the connection, refer to the operating
instructions for the synchro cable.
0 Use an external flash with a synchronisation voltage of 400 V or less.
0 Do not use the synchro cables with the length of 3 m (9.8 feet) or more.
0 The flash synchro socket has no polarity. You can use a synchro cable
regardless of its polarity.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
