Panasonic Lumix S1R User Manual

445
17. Materials
0 For information on the external flash, refer to page 216.
0 For information on the external microphone, refer to page 253.
0 For information on the XLR Microphone Adaptor, refer to page 256.
0 Some optional accessories may not be available in some countries.
Battery Grip (Optional)
When mounted on the camera, the Battery Grip
(DMW-BGS1: optional) improves ease of operation
and grip when the camera is held vertically.
Also, inserting a battery into the Battery Grip
provides a stable supply of power even for long
periods of recording.

Selecting Battery Usage Priority
Selects which battery to use first when the batteries are installed in both
the camera and the Battery Grip.
The order of battery charging using the camera body is also determined by
this setting.
Getting started:
0 Turn the camera off, and remove the cover for the battery grip connector.
1
Attach the Battery Grip to the camera.
2
Turn on the camera.
3
Set the battery use priority.
0
¨ [ ] ¨ [ ] ¨ [Battery Use Priority]
Using Optional Accessories
[BODY] The battery in the camera is used first.
[BG] The battery in the Battery Grip is used first.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
