Panasonic Lumix S1R User Manual

14. Menu Guide
309
[Focus] ¨ ¨
[AF Custom
Setting(Photo)]
`[Set 1]/[Set 2]/[Set 3]/[Set 4]
l 96
Select features of AF operation when recording
using [AFC] that are appropriate for the subject
and scene.
[AF Assist Light]
`[ON]/[OFF]
—
When recording in low light conditions, pressing
the shutter button halfway lights the AF assist
lamp, making it easier for the camera to focus.
0 The effective range of the AF assist lamp is
different depending on the lens used.
– When the interchangeable lens (S-R24105) is
attached and at Wide:
Approx. 1.0 m (3.3 feet) to 3.0 m (9.8 feet)
0 Remove the lens hood.
0 The AF assist lamp gets slightly blocked when
the interchangeable lens (S-R24105) is used,
but it does not affect the performance.
0 The AF assist lamp may be greatly blocked, and
it may become harder to focus when a lens with
large diameter is used.
0 When [Silent Mode] is being used, [AF Assist
Light] is fixed to [OFF].

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
