Panasonic Lumix S1R User Manual

14. Menu Guide
310
[Focus] ¨ ¨
[Focus Peaking]
`[ON]/[OFF]
—
[SET] [Focus Peaking
Sensitivity]
[Display Color]
[Display While AFS]
During MF operation, in-focus portions (portions
on the screen with clear outlines) are highlighted
with colour.
0 If the [Focus Peaking Sensitivity] is adjusted to
the negative direction, portions to be highlighted
are reduced, allowing you to achieve a more
precise focus.
0 With [Display Color], you can set the display
colour of the in-focus portion.
0 If [Display While AFS] is set to [ON], when the
shutter button is pressed halfway in focus mode
[AFS], you can display Peaking.
0 You can display the Touch Tab (l 333) and then
touch [ ] in [ ] to switch [ON]/[OFF].
0 When [Rough Monochrome] of [Filter Settings]
is being used, [Focus Peaking] is not available.
0 When [Live View Boost] is being used, [Focus
Peaking] is not available.
0 This menu item can be registered to the Fn
button. (l 278)

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
