Panasonic Lumix S1R User Manual

6. Focus/Zoom
118
4
Adjust the focus.
≥Rotate the focus ring.
A MF Assist (enlarged screen)
0 This will display the in-focus portion
highlighted with colour. (Peaking B)
0 A recording distance guideline is
displayed.
(MF Guide C)
D Indicator for ¶ (infinity)
5
Close the MF Assist screen.
≥Press the shutter button halfway.
≥This operation can also be
performed by pressing .
6
Start recording.
≥Press the shutter button fully.
AF
∞
10(m) 5 3 2 1.5 1 0.5 0.1

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
