Panasonic Lumix S1R User Manual

7. Drive/Shutter
173

Using the Image Stabiliser
0 When using a lens with an O.I.S. switch, set it to [ON].
0 When using lenses without a function for communicating with this camera, a
message asking you to check the focal length setting is displayed after you turn on
the camera.
Correctly operating the image stabilisation function requires that the focal length be
set to match the attached lens.
Set the focal length in accordance as prompted by the message.
This can also be set using the menu. (l 174)
0 When the shutter button is pressed halfway, the camera shake alert icon
[ ] may be displayed on the recording screen.
If this is displayed, we recommend using a tripod, the self timer or the Shutter
Remote Control (DMW-RS2: optional).
0 We recommend turning off the image stabiliser function when using a tripod.
0 The image stabiliser may cause vibration or produce operational sound during
operation, but these are not malfunctions.
0 When the following function is being used, the image stabiliser function is not
available:
– [High Resolution Mode]
0 You can display the reference point and check the camera shake status:
[] ¨ [ ] ¨ [I.S. Status Scope] (l 348)

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
