Panasonic Lumix S1R User Manual

14. Menu Guide
348
[Monitor / Display] ¨ ¨
[I.S. Status Scope]
[ON]/`[OFF]
Displays a reference point on the
recording screen in order to let you
check for camera shake.
A Reference point
0 When the following functions are
being used, [I.S. Status Scope] is
not available:
– Video recording/[6K/4K PHOTO]/[Post-Focus]
0 This menu item can be registered to the Fn button.
(l 278)
[Lens / Others] ¨ ¨
[Lens Focus
Resume]
[ON]/`[OFF]
The camera saves the focus position when you turn it off.
[Focus Ring
Control]
`[NON-LINEAR]/[LINEAR]
[SET] [90°] to [360°] (`[150°])/[Maximum]
Sets the amount of movement for focusing using the focus
ring. (When using supported lenses)
0 The interchangeable lens (S-R24105) supplied with Lens
Kit products supports this function.
[NON-LINEAR]: Focus responds by accelerating according
to rotation speed of the focus ring.
[LINEAR]: Focus responds at a constant amount according
to the rotational angle of the focus ring.
[SET]: Sets the rotational angle of the focus ring for when
[LINEAR] is selected.
0 This menu item can be registered to the Fn button.
(l 278)

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
