Panasonic Lumix S1R User Manual

7. Drive/Shutter
165

Focus Position Selection Operations
Button
operation
Touch
operation
Description of operation
3421/
/
Touch
Selects a focus position.
0 Selection is not possible during enlarged
display.
Enlarges the display.
0 During enlarged display, you can fine-adjust the
focus by dragging the slide bar.
(You can also perform the same operation by
pressing 21.)
Reduces the display (during enlarged display).
[] Switches to Focus Stacking operation. (l 166)
s
Displays the in-focus portion highlighted with
colour ([Focus Peaking]).
0 Switches in the order of [OFF] > [ON].
/ Saves the picture.
0 You cannot display an image on a TV screen and then select the focus
position.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
