Panasonic Lumix S1R User Manual

11. Recording Videos
252

Setting the Information Display During HDMI Output
Select whether or not to output the information display of the camera to an
external device connected via HDMI.
¨ [ ] ¨ [ ] ¨ [HDMI Rec Output] ¨ Select [Info Display]
Settings: [ON]/[OFF]
0 When you use the HDMI output during recording, the image may be displayed
with a time lag.
0 Beep sounds, AF beep, and electronic shutter sounds are muted during HDMI
output.
0 When you check the image and audio from the TV connected to the camera,
the microphone of the camera may pick up the sound from the speakers of the
TV, producing an abnormal sound (audio feedback).
If this occurs, move the camera away from the TV or lower the volume on the
TV.
0 Certain setting screens are not output via HDMI.
0 There is no output via HDMI while you are using the following functions:
– [6K/4K PHOTO]/[Post-Focus]

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
