Panasonic Lumix S1R User Manual

11. Recording Videos
254
3
Connect the camera and external microphone.
0 If mounting the external microphone on the camera hot shoe A, remove the
hot shoe cover. (l 216)

Setting the Sound Pickup Range (DMW-MS2: Optional)
When using the Stereo Shotgun Microphone (DMW-MS2: optional), you
can set the microphone sound pickup range.
1
Select [Special Mic.].
0
¨ [ ] ¨ [ ] ¨ [Special Mic.]
2
(When [MANUAL] is selected)
Press 21 to adjust the sound pickup range and then press or
.
0 Do not use the stereo microphone cables with the length of 3 m (9.8 feet) or
more.
[STEREO] Picks up sound over a wide area.
[LENS AUTO]
Picks up sound from a range automatically set by the lens
angle of view.
[SHOTGUN]
Helps prevent picking up background noise, and records
sound from a specific direction.
[S. SHOTGUN]
Narrows the sound pickup range more than with
[SHOTGUN].
[MANUAL] Sets the range manually for sound pickup.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
