Panasonic Lumix S1R User Manual

6. Focus/Zoom
111
3
Select the AF area.
≥Touch operation
Touch the area to make the AF area.
0
To select consecutive points, drag the
screen.
0 To cancel selection of the selected AF
area, touch it again.
≥Button operation
Press 3421 to select the AF area and then set with or .
(Repeat this)
0
Positions can be moved to the diagonal directions using the joystick.
0 To cancel selection of the selected AF area, press or again.
0 To cancel all selections, press [DISP.].
4
Press [Q].

Move the Position of the AF Area
1
Press [ ] to display the AF mode selection screen.
2
Select a registered AF mode shape ([ ] to [ ]) and then press 4.
3
Press 3421 to move the position of the AF area and then press
.
0
Positions can be moved to the diagonal directions using the joystick.
0 Press [DISP.] to return the [i] position to the centre.
ヤヒ
ヤピ

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
