Panasonic Lumix S1R User Manual

7. Drive/Shutter
162
2
Close the menu.
≥Press the shutter button halfway.
3
Decide on the composition
and then adjust the focus.
≥Press the shutter button halfway.
≥AF detects the focus position on the
screen. (Excluding the edges of the
screen)
0 If no areas on the screen can be brought into focus, the focus indication (A)
blinks and recording is not possible.
0 Maintain the same distance to the subject and the same composition until
recording finishes.
4
Start recording.
≥Press the shutter button fully.
0
Recording is performed while
automatically changing the focus
position.
When the icon (B) disappears, recording
ends automatically.
0 A video will be recorded with [Rec. File
Format] set to [MP4]. (Audio will not be recorded.)
0 In default settings, Auto Review operates, and a screen that lets you select
the point to be focused will be displayed. (l 164)
ISO 10F4.060
±
0

9m59s


Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
