Panasonic Lumix S1R User Manual

7. Drive/Shutter
168

Operations when [Range Merging] is Selected
Button
operation
Touch
operation
Description of operation
3421 /
/ /
Touch Selects a point.
[] [Set/Cancel] Sets or cancels a point.
[DISP.]
[All]
Selects all points.
(Before selecting points)
[Reset]
Cancels all selections.
(After selecting points)
/
Merges the pictures and saves the resulting
picture.
0 The picture is saved in JPEG format, and the recording information (Exif
information), such as the shutter speed, aperture, and ISO sensitivity, of the
picture with the closest point is also saved with the picture that is saved.
0 Image misalignment due to camera shake will be adjusted automatically. If
adjustments are made, the angle of view will become slightly narrower when
the pictures are merged.
0 If the subject moves during recording or the distance between subjects is
great, merging may create an unnatural picture.
0 Focus Stacking may not be available for images recorded with other than this
camera.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
