11. Recording Videos
250
4
Fit the USB connection cable (C–C or
A–C) (F) and HDMI cable (G) to the
clamp.
5
Slide the clamp portion (H) to attach it
to the cable holder.
6
Connect the USB connection cable
(C–C or A–C) to the USB port (I).
7
Connect the HDMI cable to the [HDMI]
socket (J).
K Leave some slack so that this section
has a length of at least 10 cm (0.33 feet).
Removing the cable holder
To remove the cable holder, follow the steps for attaching it in the reverse
order.
0 Do not use any other USB connection cables except the supplied USB
connection cables (C–C and A–C).
0 We recommend using an HDMI cable with a thickness diameter of 6.5 mm
(0.26 inch) or less.
0 It may not be possible to attach HDMI cables of certain shapes.
