Panasonic Lumix S1R User Manual

11. Recording Videos
258

Switching the Sound Output Method
¨ [ ] ¨ [ ] ¨ Select [Sound Output]
0
When recording with an HDMI connection, this is fixed to [REC SOUND].

Adjusting the Headphone Volume
Connect the headphones and rotate .
0
You can also adjust the volume by touching [ ]/[ ] on the playback screen.
To adjust the volume using the menu:
1
Select [Headphone Volume].
0
¨ [ ] ¨ [ ] ¨ [Headphone Volume]
2
Press 34 to adjust the headphone volume and then press or
.
0
It can be adjusted in a range of [0] to [LEVEL15].
[REALTIME]
Audio without time lag.
It may differ from the sound recorded in videos.
[REC SOUND]
Audio to be recorded in videos.
Output sound may be delayed from actual sound.
: Reduces the volume.
: Increases the volume.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
