14. Menu Guide
337
[Operation] ¨ ¨
[Dial Set.]
(Continued)
[Exposure Comp.] [ ]/[ ]/`[OFF]
Assigns exposure compensation to or . (Except in
[M] mode)
0 The [Assign Dial (F/SS)] setting takes priority.
[Dial Operation
Switch Setup]
[]
[]
In the Fn button [Dial Operation Switch], this sets the items
to be assigned temporarily to or . (l 289)
[Rotation (Menu
Operation)]
`[]/[]/
[ ]/[ ]
Changes the rotational direction of the dials when operating
menus.
[Joystick Setting]
`[D.FOCUS Movement]/[Fn]/[MENU]/[OFF]
Sets the joystick movement on the recording screen.
[D.FOCUS Movement]: Moves the AF area and MF Assist.
(l 112, 117)
[Fn]: Operates as the Fn button.
[MENU]: Operates as . Operations that can be
performed by moving the joystick are disabled.
[OFF]: Disables the joystick.
[Illuminated Button]
[ON1]/`[ON2]/[OFF]
Sets the lighting timing of the illumination button.
The following illumination buttons light:
–[(] button/[Q] button/[ ] button/[ ] button/[DISP.]
button
[ON1]: Buttons are always lit while the camera is turned on.
[ON2]: Buttons are lit when [ ] is pressed. If no
operations are performed for approx. 5 seconds, this turns
off.
[OFF]: The buttons are not lit.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix S1R and is the answer not in the manual?

Panasonic Lumix S1R Specifications

General IconGeneral
Sensor Resolution47.3MP
Sensor TypeFull-frame CMOS
ISO Sensitivity100-25600 (expandable to 50-51200)
Image ProcessorVenus Engine
Image Stabilization5-axis in-body image stabilization
Camera TypeMirrorless
Sensor Size36 x 24 mm
Lens MountL-Mount
Shutter Speed1/8000 to 60 sec, Bulb
ConnectivityWi-Fi, Bluetooth
BatteryDMW-BLJ31 Lithium-Ion
Dimensions148.9 x 110.0 x 96.7 mm
Autofocus SystemContrast Detection AF System with DFD Technology
Viewfinder5.76 million dots OLED EVF
LCD Screen3.2-inch, 2.1 million dots, touch screen
Video Recording4K up to 60p
Continuous Shooting9 fps (AFS/MF), 6 fps (AFC)
Weather SealingYes
Memory Card Slots2x SD Card Slots (1x UHS-II Compatible)
