Panasonic Lumix S1R User Manual

14. Menu Guide
343
[Monitor / Display] ¨ ¨
[Night Mode]
[Monitor] [ON]/`[OFF]
[LVF] [ON]/`[OFF]
Displays monitor and viewfinder in red.
In dark environments, this reduces brightness of the screen
that can make the surroundings difficult to see.
You can also set the luminance of the red display.
1 Press 3421 to select [ON] on the monitor or
viewfinder (LVF).
2 Press [DISP.] to display the brightness adjustment
screen.
0 Display the monitor to adjust the monitor, and display
the viewfinder to adjust the viewfinder.
3 Press 21 to adjust luminance and then press or
.
0 This effect is not applied to images output via HDMI.
0 This menu item can be registered to the Fn button.
(l 278)
[LVF/Monitor Disp.
Set]
[LVF Disp. Set] []/`[]
[Monitor Disp. Set] []/`[]
You can select whether to display the live view in full screen
or to avoid covering the information display.
[]: Scales down images slightly so
that you can better review the composition
of the images.
[]: Scales images to fill the entire
screen so that you can see their details.
999
±
0
AFSAFS
L
FINE
AFSAFS
999
±
0
L
FINE

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
