17. Materials
464
0 If no operations are performed during the set time period, [Auto LVF/Monitor Off]
(l 44) is activated, and the Monitor/Viewfinder turns off.
0 When an object or your hand is positioned near the eye sensor, the Monitor display
may switch to the Viewfinder display.
0 This occurs when the shutter button is pressed halfway, or when the subject
brightness changes, making the lens aperture change.
This is not a malfunction.
0 When the camera is connected to a PC or printer, it is not possible to switch to the
viewfinder display.
0 The viewfinder of the camera is built with OLED components Screen burn-in may
occur on the screen/viewfinder when a same image is displayed for a long period of
time, but it does not affect the recorded images.
0 This is characteristic of the viewfinder of the camera and not a malfunction.
It does not affect the recorded images.
0 The flash does not fire when using the following functions:
– Video recording (l 230)/[6K/4K PHOTO] (l 130)/[Post-Focus] (l 161)
– [ELEC.] (l 170)/[Silent Mode] (l 169)/[High Resolution Mode] (l 210)
– [Filter Settings] (l 204)
Monitor/Viewfinder
The monitor/viewfinder turns off when the camera is turned on.
It may flicker for an instant or the brightness of the screen may
change significantly for an instant.
Cannot switch between the monitor and viewfinder even when [LVF]
is pressed.
Unevenly bright parts or irregular colours appear on the viewfinder.
The colouring of the viewfinder differs from the actual tone.
Flash
The flash does not fire.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix S1R and is the answer not in the manual?

Panasonic Lumix S1R Specifications

General IconGeneral
Sensor Resolution47.3MP
Sensor TypeFull-frame CMOS
ISO Sensitivity100-25600 (expandable to 50-51200)
Image ProcessorVenus Engine
Image Stabilization5-axis in-body image stabilization
Camera TypeMirrorless
Sensor Size36 x 24 mm
Lens MountL-Mount
Shutter Speed1/8000 to 60 sec, Bulb
ConnectivityWi-Fi, Bluetooth
BatteryDMW-BLJ31 Lithium-Ion
Dimensions148.9 x 110.0 x 96.7 mm
Autofocus SystemContrast Detection AF System with DFD Technology
Viewfinder5.76 million dots OLED EVF
LCD Screen3.2-inch, 2.1 million dots, touch screen
Video Recording4K up to 60p
Continuous Shooting9 fps (AFS/MF), 6 fps (AFC)
Weather SealingYes
Memory Card Slots2x SD Card Slots (1x UHS-II Compatible)
