Panasonic Lumix S1R User Manual

17. Materials
473
Removing dirt on the image sensor
The image sensor is very precise and delicate, so be sure to observe the
following when you do have to clean it yourself.
0
Blow dust off the surface of the image sensor using a commercially available blower.
Do not blow the dust off with excessive power.
0 Do not put the blower brush further inside than the lens mount.
0 Do not let the blower brush touch the image sensor as the image sensor may get
scratched.
0 Do not use any objects except a blower brush to clean the image sensor.
0 If you cannot remove the dirt or dust with the blower, consult the dealer or
Panasonic.

Cleaning the Viewfinder
If the viewfinder is dirty, then remove
the eye cup and clean.
While pushing the eye cup lock lever
(1), rotate the eye cup in the
direction of the arrow and remove
(2).
Blow dirt off the surface of the
viewfinder using a commercially
available blower, then lightly wipe
with a soft, dry cloth.
0
After cleaning, align the fitting marks (#)
3 and rotate the eye cup in the direction
of the arrow until a click is heard (4).
0 Be careful not to lose the eye cup.
 




Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
