Parker Hannifin S.p.A. Divisione S.B.C. user’s manual TWIN-N and SPD-N
131
Alarm message from the drive to the master
Error
Data length
3 bytes
Field Name
Addr Error
Contents
Pr27+1 Pr23
Identifier
ID2 ID1 ID0 - - - - - ID10 ID9 ID8 ID7 ID6 ID5 ID4 ID3
A2 A1 A0 X X X X X 0 A4 0 1 0 0 0 A3
A0:A4 drive slave address (Pr27+1), valid values 1..31.
If the converter is in the alarm status, it will send this message on the bus (alarm 0 = no
alarm).
10.1.3 Description of the fields Extended message set # 2
The extended message set 2 permits a memory area exchange between the master and the
drive with both communication and real-time mode. The data exchange is synchronous: the
data, transmitted from the master to the device, are stored in a temporary buffer; when the
master sends the synchronous message to all the drives, each device copies the temporary
buffer onto the writing block area and sends back the reading block area.
Block send message from the master to the drive
Block send
Data length
8 bytes
Field Name
Data
Contents
64 bit of data
Identifier
ID2 ID1 ID0 - - - - - ID10 ID9 ID8 ID7 ID6 ID5 ID4 ID3
A2 A1 A0 X X X X X 1 0 0 0 0 0 1 A3
A0:A3 drive slave address (Pr27+1), valid values 1..15.
