Parker Hannifin S.p.A. Divisione S.B.C. user’s manual TWIN-N and SPD-N
15
1.4.10 Warranty
The warranty duration if 1 (one) year. The converter must not be opened, accessed or modified in any
of its part. Any attempt to do so would cause the 1-year warranty to be cancelled with immediate
effect.. Parker Hannifin declines any responsibility for damages that may be caused by inappropriate
use of the converter.
1.5 Main hardware features
1.5.1 Ambient conditions
operation
0 … 45 °C
32 …113 °F
storage
(1K4 class)
-20 … 55 °C
-4 …131 °F
temperature
transportation
(2K3 class)
-25 … 70 °C
-13…158 °F
relative
< 85% without ice and condensation
humidity
(3K3 class)
absolute < 25 g/m
3
altitude (*)
≤ 1000 m slm
≤ 3281 feet asl
Protection degree
IP20 (only in close electric cabinet)
UL open type equipment
Pollution degree
2 or lower
(no conductive dust allowed)
(*) For higher installation altitude, derate the output current by 1.5% each 100m up to 2000m
maximum
