1.3 Identification
The converters of the TWIN-N series are available in 3 models: TWIN 2N, TWIN 5N and TWIN 8N.
The number that follows the TWIN-N abbreviation corresponds to the rated current of the converter
in amperes.
Use the following table to specify the order code:
TWIN 2 N S
X 5 C E Y1 R
8 D H
F
The converters of the SPD-N series are available in 4 models: SPD 2N, SPD 5N, SPD 8N and
SPD16N. The number that follows the SPD -N abbreviation corresponds to the rated current of the
converter in amperes.
Use the following table to specify the order code:
SPD
2 N S
X 5 C E Y1 R
8 D H
16 F
Where :
TWIN / SPD TWIN / SPD servodrive series
X ATEX type drive
2 drive size (nominal current, up to 1 digit: 2, 5, 8, 16)
N New series
S SBC Can protocol (standard)
C CAN Open protocol (DS301)
D CAN Open protocol (DS402)
Resolver
E EnDat/incremental/sinc encoder input (from motor feedback)
H Incremental encoder+hall sensors input (from motor feedback)
F SinCos (one wave per pole pitch)
Y1 Optional board
R Internal safety relay
A label is attached on the right side of the converter that contains all the essential information to
correctly identify the unit:
Serial number
Model
Nominal plate data
It is important to refer to this label before requesting any kind of technical information from Parker
Hannifin S.p.A S.B.C. Division
