Parker Hannifin S.p.A. Divisione S.B.C. user’s manual TWIN-N and SPD-N
24
2.2 Signal connectors layout
Power terminal connections
1 L1
2 L2
3 L3
LINE
4 earth
5 U-I
6 V-I
7 W-I
MOTOR I
8 earth
9 U-II
10 V-II
11 W-II
MOTOR II (only TWIN-N)
12 +BUS
13 Int-res
14 Com-brk
15 -BUS
BUS CONFIGURATION
I axis terminal connections
1 Rif. AUX + Rif. Analog + 25
2 Rif. AUX - Rif. Analog - 26
3 0VA (0V Analog) 0VA (0V Analog) 27
4 Vout ECC+ 28
5 0VA (0V Analog) ECC- 29
6 IN0 SIN+ 30
7 IN1 SIN- 31
8 IN2 COS+ 32
9 IN3 COS- 33
10 0VQ (0V Quadro) 0VA (0V Analog) 34
11 OUT0 PTC+ 35
12 OUT1 PTC- 36
13 A+ ENCODER OUT A+ ENCODER IN 37
14 A- ENCODER OUT A- ENCODER IN 38
15 B+ ENCODER OUT B+ ENCODER IN 39
16 B- ENCODER OUT B- ENCODER IN 40
17 C+ ENCODER OUT C+ ENCODER IN 41
18 C- ENCODER OUT C- ENCODER IN 42
19 0VE (0V Encoder) 0VE (0V Encoder) 43
20 CK+ DATA+ 44
21 CK- DATA- 45
22 IN4 + 5VE (Supply ENCODER) 46
23 IN5 0VE (0V Encoder) 47
24 0VQ 0V SUPPLY +24V IN SUPPLY 48
