Parker Hannifin S.p.A. Divisione S.B.C. user’s manual TWIN-N and SPD-N
152
10.3.2.5 Object 605Ah: Quick stop option code
The parameter
quick stop option code determines what action should be taken if the Quick
Stop Function is executed.
OBJECT DESCRIPTION ENTRY DESCRIPTION
INDEX 605Ah
Name Quick stop option code
Object Code VAR
Data Type INTEGER16
Category Optional
Access rw
PDO Mapping No
Value Range INTEGER16
Default Value 2
DATA DESCRIPTION
Value Description
0 disable drive function
1 slow down on slow down ramp
2 slow down on quick stop ramp
5 slow down on slow down ramp and stay in QUICK STOP
6 slow down on quick stop ramp and stay in QUICK STOP
10.3.2.6 Object 605Eh: Fault reaction option code
The parameter
Fault reaction option code determines what action should be taken if a fault
occurs.
OBJECT DESCRIPTION
INDEX 605E
h
Name Fault reaction option code
Object Code VAR
Data Type INTEGER16
Category Optional
ENTRY DESCRIPTION
Access rw
PDO Mapping No
Value Range INTEGER16
Default Value 2
