14 Appendix D: default program for pico-PLC
90.0
40.6
END
41.5
90.1
91.041.4
91.141.11
LD 90.0
OUT 41.5
LD 90.1
OUT 40.6
LD 41.4
OUT 91.0
LD 41.11
OUT 91.1
END
digital input 0 used to power the
drive
digital input 1 used for the stop
function
digital output 0 indicates that the
converter is OK
digital output 1 indicates that the
thermal motor image is active
end of the pro
g
ram
