Adjusting the Chassis Entrance Brush Height
Thechassisentrancebrushassistsincontrollingcollationsfedfromthebufferdumpstationtothe
chassis.Thebrushheightisadjustableviaaheightadjustmentscrew.Typicallythebrushwillnotrequire
adjustmentbetweensimilarjobs.
Ifjamsoccuratthechassisentrancewherethepushersjamagainstthecollation,thebrushmayhaveto
beraisedslightly.
Ifthecollationispushedaheadofthechassispusherscausingstoppagesofthesystem,thebrushmay
havetobelowered.
Toadjusttheheightofthebrush:
1. Opentherightbuffercovertoaccessthebrush.
2. Useanoperatortooltoadjustthebrushheightscrew.

o
Clockwiseraisesthebrush

o
Counterclockwiselowersthebrush
Item Description
1 ChassisEntranceBrush
2 BrushHeightScrew
AdjustChassisEntranceBrush
