Setting Up the RAT (Right Angle Transfer)
TheRATchangesthedirectionoftheenvelope90degreestobetransporteddownstreamtotheoutput.
Adjusting the Roller Tension
ThisistheonlyoperatoradjustmentintheRATarea.
1. Opentheengineandsealertopcovers.
2. Locatetheadjustablerollerlockingscrewforthetwoexitrollers.
Item Description
1 Tensioner
2 LockingScrew
RATRollerTensionandLockingScrew
3. Usinga3/16"setuptool,loosenthelockingscrew.
4. Withthelockingscrewloose,adjustthetensionoftheroller.(The left side is lighter, press to the
right is more pressure.)
5. Tightenthelockingscrew.
Operator Adjustments
