Adjusting the Rotary Feeder Separator Pins
Theseparatorpinsintherotaryfeederpreventmultiplepiecesofmaterialfrombeingpulledintothe
feederatonce.
Therearefourseparatorpinslocatedonthecentergate.Thetwoinnerpinsareclosesttothecenterof
thegateandthetwoouterpinsareclosertothesuctioncups.
l Innerpins-usedformostmaterial
l Outerpins-usedforunusualinserts(booklets)toallowsthestapletomissthepins
RotaryFeederSeparatorPins(outer pins shown here)
Operator Adjustments
Pitney Bowes Epic Select Operator Guide December,2017 Page 133 of 288
