Adjusting Chassis Material Center Deck Control Straps
Chassismaterialcontrolstrapsarelocatedinfrontofeachfeederandtheysupportthecollationasit
travelsdownthelengthofthechassis.Thestrapsareadjustedtoprovidetheproperamountofpressure
oneachmailpieceandtocenterthecollationwhenthechassisstops.
Toadjustthematerialcontrolstraps:
1. Starttheinserterandrunajob.
2. Whenthechassisdeckisfull,stopthemachinewiththeremoteorusingDC.
3. Viewthecollations/mailpiecesrestingunderneatheachfeeder.
a. Ifcollation/mailpieceismorethan1-inchawayfromthepushers,loosenthelockdownscrew
withtheOperatorsetuptoolandrotatetheindicatorlevertotheright totighten strappressure.
b. Ifthecollation/mailpieceisbuckledatthepusher,loosenthelockdownscrewwiththe
Operatorsetuptoolandrotatetheindicatorleveltotheleft toloosen strappressure.
Item Description
1 LockdownScrew
2 IndicatorLever
AdjustChassisMaterialControlStraps
4. Runmorematerialandadjustthestrapsasneededuntiltheproperpositionisachieved.
