About Engine Horns
Enginehornsareusedtofunnelthematerialfromtheinsertareaintotheenvelope.Therearethree
differenttypesofhorns,basedonsize,thatcanbeinstalledontheengine-standardornarrow.Horn
typeisselectedbasedoncollationthicknessorenvelopesize.
Horn Descriptions

HornTypes
Item Description
1 NarrowHorn(3mm)
2 StandardHorn(standard8mm)
l Narrowhorn-usedwhentheenvelopeis8"orlessandwhenthecollationthicknessislessthan
3mm.Usedforapplicationswithtightendclearance.
l Standardhorn-usedforallapplicationsupto8mminthickness.
Usethehornthatissavedtothemode,otherwisetimingandadjustmentsmaynotbeproperly
completed.
