Adjusting the Feeder Pack Control Ramp
Thepackcontrolramphelpsrelieveweightofftheinsertsastheyarefedintotheseparator.Italsokeeps
thematerialataconsistentangleforfeedingintotheseparator.Thereisonefeederpackcontrolrampin
eachfrictionfeeder.
Toadjustthepackcontrolramp:
1. Loosenthepackcontrolknob.
Item Description
1 PackControlGuide
2 PackControlKnob(slides to the right)
PackControlKnob
2. Slidethepackcontrolguidetotheright.
3. Placea1-inch(25mm)stackofmaterialbetweenthesideguidesatthesameheightasthetopof
thepackcontrolramp.
