Adjusting the Rotary Feeder Side Guide and Backstop
1. Placethematerialonthedeckagainstthefeedcentergate.
2. Loosenthebackstoplockingknob.
3. Pushthebackstop(forwardorbackward)againstthematerialandlocktheknobinplace.(Do not
move the backstop too close to the material as it can restrict the material from dropping to the deck
naturally.)
Item Description
1 CenterGate
2 Backstop
3 BackstopLockingKnob
4. Loosenthesideguidelockingknobs.
Operator Adjustments
