Adjusting the Chassis Side Guides
Thechassissideguidesrunthelengthofthechassisandtheyguidethematerialfromtheinputtothe
engine.Thereareguidesonboththeoperatorandnon-operatorsides.Oncetheengineobservation
guidesaresetyoucanadjustthechassissideguides.
Followthesestepstoadjustboththeoperatorandnon-operatorsideguides.
1. Verifytheobservationsideguidesareproperlysetintoposition.
2. Openthefeederdoors.
3. Grasptheleftandrightsidesoftheoperatorchassissideguideandbeginmovingtheguidesoit
sitsabout1mminsidetheengineobservationguidewheretheymeet.This setup creates a funnel
like effect so the material does not get caught on the observation side guide entrances when
exiting the chassis.
AdjustChassisSideGuides-feeders open here to show procedure
UsetheDeckScaleforReferencePoints
Operator Adjustments
Pitney Bowes Epic Select Operator Guide December,2017 Page 101 of 288
