Setting the Suction Cup Position
1. Jogthefeedersothearmisinthehorizontalposition.
2. Loosenthesuctioncuparmlockingscrew.
3. Usingthescaleonthesuctioncuparm,movethearmtogetthesuctioncupsintheproper
position.
Item Description
1 LockingScrew
2 SuctionCupArm
3 Scale
PositionSuctionCup
Operator Adjustments
Pitney Bowes Epic Select Operator Guide December,2017 Page 126 of 288
