About Suction Cup Types and Positions
Therearetwodifferenttypesofsuctioncups-shortandtall.Thetypeofcupyouusedependentsonthe
typeofmaterialyouarerunning.
Suctioncuppositionisalsodeterminedbythetypeofmaterialyouarerunning.Refertothetable
includedheretodeterminethepropersuctioncuptypeandpositionforyourjob.
MaterialType CupType CupPosition
Singlesheet-#10,A4(singlesheet) short,bluering 0
Half-fold,non-glossy(singlesheet) short,bluering 0
Half-fold,glossy(singlesheet) short,bluering 0-1
Folded,perfume tall,redring 1
BRE tall,redring 0
Booklet(thick.125"max) tall,redring 1
Booklet(thin) short,bluering 1
Operator Adjustments
