3. Releasethebufferhandleandthebufferlocksdownintothefoldposition.
BufferLockedDownintotheFoldPostion
4. GraspbothspringloadedlockingpinhandlesandpulltheminwardstoreleasetheTIM.
5. Whileholdingthespringloadedlockingpinhandles,pulltheTIMmoduleupandoutoffoldplate
slot#1.
6. Oncethelockingpinsclearthetopofthefoldplateslot,thehandlesmaybereleased.
7. Installthefoldplatesasnecessary.
Note:
WhenyouarenotusingtheTIMmodule,storetheassemblysafelytoavoiddamage.
