Physical Characteristics
ThephysicalcharacteristicsoftheEpicsystem:
l Length(alongchassis):88"(226cm)
l Width(alongoutput):101"(257cm)
l Height:44"(112cm)
l HeatDissipation:2000watts(6824BTU/hr)
l Airrequirements:6.3SCFM@70PSI
l TotalWeight:1790lbs(812kg)

o
Engine=1000lbs

o
Sealer/VBin=455lbs

o
EnvelopeFeeder=335lbs
Air Consumption
WorsecaseairconsumptionforaZVE2,21-stationchassis,8-stageTNTbufferis6.5SCFM.
SystemAirConsumption Case#1 Case#2
 #10@21K(SCFM) subsetflatsat7.2K
(SCFM)
Engine 6.44 2.98
21-stationchassis 0.010 0.292
8-stageTNTbuffer 0.001 0.159
Engine,chassis,buffertotalconsumption 6.45 3.43
Case#1:21K,#10,decknipsoperate1%oftimeforstopconditions.Subsetstopsandjoggerinactive.
Case#2:Flatsmode,twosubsetsoffivepageseach.Chassisspeedof7.2K,joggeractivates2xper
collation.Subsetstopsactivate1xpercollation.Alldecknipsgoupanddown1xpercycle.
Specifications
