Horns
Twosetsofhornsareprovided:
  MaxCollation
Thickness
MinimumEnd
Clearance(total)
Minimum
EnvelopeWidth
(mm)

Left
Horn
Right
Horn
mm inches mm inches mm inches
NarrowEnvelopes
zy56464 zy56465 3 0.12 10 0.37 177.6 6.99
StandardEnvelopes
zy56452 zy56451
8 0.32 
15 0.58 194.8 7.67
Engine Horns

End Clearance
Endclearanceisthedifferencebetweenthedimensionofthelargestinsertandthelengthofthe
envelopewhenmeasuredwithallinsertsintheenvelope.
A.75"(19mm)endclearanceisrecommendedtoachievemaximumthroughputforallcategories.
Experiencehasshownthatendclearancerequirementsincreasewiththeheightofthecollationand/or
withthenumberofpagescomprisingtheinputdocument.
Specifications
