Cycling Speed Specifications
ThistableapproximatesthemaximumsystemthroughputbasedonamathematicalmodeloftheMPS
insertionengine.
 EnvelopeDepth EnvelopeWidth FlapDimension
(Min)
FlapDimension
(Max)
Maximum
CycleRate
(env/hr)
Envelope inches mm inches mm inches mm inches mm 
#73/4orMonarch 3.95 98 7.500 191 1.25 32 1.75 44 21K
#10 4.10 105 9.500 241 1.25 32 1.75 44 21K
ISODL 4.30 110 8.7 220 1.25 32 1.75 44 21K
C6/5 4.50 114 9.0 229 2.25 57 2.75 70 21K
#14 5.00 127 11.5 292 1.25 32 1.75 44 19K
6x9 6.00 152 9.00 229 1.25 32 1.75 44 18K
C5 6.40 162 9.00 229 1.25 32 1.75 44 18K
9x12 9.00 229 12.0 305 1.75 44 2.25 57 14K
C4 9.00 229 12.8 324 1.75 44 3.25 83 14K
B4 9.80 250 13.8 350 1.75 44 5.25 133 14K
10x13 10.0 254 13.0 330 1.75 44 4.25 108 14K

