6. Installingthehornstrap:
a. Ifyouareinstallingthenarrowhorns,installthenarrowstrap.Ifyouareinstallingthestandard
orwidehorns,installthewidestrap.
b. Selectthecorrectwidthandorientation(leftorright)andslidetheslottedmountingbracket
underthemountingscrewandbetweenthehornopening.
c. Tightenthehornmountingscrewinplaceandverifythatthehornpivotsfreelywithoutbinds.
Item Description
1 MountingScrew
2 HornStrap
3 Horn
InstallHornStrap
7. Loadthemodeforthenewapplication.
Operator Adjustments
Pitney Bowes Epic Select Operator Guide December,2017 Page 70 of 288
