Figure 5.1: Elevation Views
60.5"
(1537 mm)
10"
(254
mm)
14"
(356 mm)
(Drop
Stacker)
33.5"
(851 mm)
14.5"
(368 mm)
89" LOA
(2261 mm)
38.75"
(984 mm)
31"
(787 mm)
60.5"
(1537 mm)
10"
(254
mm)
29"
(737 mm)
118" LOA
(2997 mm)
14.5"
(368 mm)
28.6"
(726 mm)
14"
(356
mm)
(Drop
Stacker)
33.5"
(851 mm)
31"
(787 mm)
NOTE: System depth is 22.8 in (579 mm). Drawings are not to scale. All dimensions approximate. The
Relay 5000/6000 does not include the High Capacity Envelope Feeder.
