SV63136 Rev. A
6-13
Specifications • 6
HCSF - Sheet Specifications
Parameter Minimum Value Maximum Value
Width
7.99 inches (203 mm) 8.5 inches (216 mm)
Length 9.15 inches (232mm) 11.69 inches (297 mm)
Basic Weight 20 lb. (80 gsm) 24 lb. (90 gsm)
NOTES:
• All sheets within a collation shall be within 0.37" (10 mm) of each other in
length.
• Maximum material thickness for feeders: 0.007" (0.18 mm) when scanning,
otherwise 0.25 mm (0.009").
Contaminants
Materials with visible material loss (loose powder, ink, surface glaze, etc.)
when hung free over a clean surface and struck sharply with a standard
wood ruler should not be used.
Special Materials
• Do not use materials that are sensitive to heat (such as thermal papers).
• Do not use materials that are sensitive to minor magnetic fields.
• Do not use pressure-sensitive materials.
Materials Not
Certified for Use
